Electrical parameters:
1.Frequency range: 820-960MHz
2.Polarization: ±45°
3.Gain: 15dbi
4.Down-tilt:0-14°
5.Beam width: Hor65°±5/Ver≥15°
6.Cross polarization ratio: axis direction≥20, ±15°≥15
7.Front-to-back ratio:>28dB
8.Upper side-lobe restrain: ≥16dB
9.VSWR: ≤1.5
10.Isolation degree:>28dB
11.Third order intermodulation: <-107dBm
12.Input impedance: 50Ω
13.Power capacity: 250W
14.Interface type 2*7/16’’ DIN Female
Product feature:
This product is widely used at building construction foundation installation and anchorage installation against the wall whose appearance is environmental harmony. It also owns features of easy installation and easy maintenance.
